RGBW Pixles LED Strip

SM16704 RGBW Addressable digital led strip 60leds/m DC24V
  • SM16704 RGBW Addressable digital led strip 60leds/m DC24V
  • SM16704 RGBW Addressable digital led strip 60leds/m DC24V
  • SM16704 RGBW Addressable digital led strip 60leds/m DC24V
  • SM16704 RGBW Addressable digital led strip 60leds/m DC24V

SM16704 RGBW Addressable digital led strip 60leds/m DC24V

Specifications:
LED Source: 5050SMD RGBW SM16704 chipset
IC Type: SM16704
Working Input Voltage: DC 24V
Output Power: 0.3w/ leds
Drive Mode: Contant Voltage
LED Quantity: 60 leds/Meter ( 24V:6LEDs is separately controlled)
IC Quantity: 10 IC/Meter (24V:1 IC drives 6 led chip)
Pixels: 10 Pixels/Meter
Grey scale: 256
Color: RGB+W(6000K),RGB+WW(3000K)
View Angle: 120°
Working Tempreture: -20° to 60°
PCB Color: White PCB
Waterproof: IP30: Non- waterproof, IP67: Waterproof in SiliconTube
PCB Width: 60LEDs/m-12mm
Power: 60LEDs/meter - max 18W/Meter
    1.DC24V 60LED per meter SM16704 RGBW LED pixel strip Advantage:
    2. IC embedded, save space and cost
    3. 6LEDs per pixel, controlled individually, show customized color effects
    4. Cuttable for each 6LED
    DC24V 60LED per meter SM16704 RGBW LED pixel strip Connection:
    DC+: connect to power supply DC+
    DAT: connect to controller DAT
    GND: connect to power supply GND & controller GND
    File Name : Format: Size: Download:
    SM16704-60LED PDF 562.73 KB
